Features:

• STIHL Quick Chain Tensioning (B)- The STIHL chain quick tensioning system (B) makes it very easy to tension the chain. Just release the sprocket cover and turn the knob to set the optimum tension. No tools needed.
• Ematic chain lubrication system - The STIHL Ematic chain lubrication system provides maximum lubrication, longer wear and less oil consumption that conventional methods of chain lubrication. The oil consumption can, therefore, be reduced by up to 50%.
• Two-handled operation - The ergonomically shaped handle and rear control handle with comfortable soft-grip components ensure safe working in all operating positions.
• Operating handle - The black soft component on the rear handle provides a secure and firm grip in all working positions.
• Toolless filler cap - The tank can be filled quickly and easily using the toolless filler cap.
• STIHL Electric Motor (EC) - The STIHL electric motor (EC) is extremely energy efficient, lightweight and compact. It runs quietly, generates very low vibrations and does not require servicing.



Technical Data:

• Weight kg 1) - 5.3
• Bar length cm - 35
• Bar length in - 14
• Oil tank volume oz - 7.1
• Oil tank volume cm3 - 210
• Rated current A - 50
• Rated voltage V - 36
• A (8) Daily vibration load - right m/s2 - 1
• Sound pressure level dB(A) 2) - 85
• Sound power level dB(A) 3) - 93
• Vibration levels left/right m/s 4) - 4.6/3.9
• Working time with AP 300 S battery min 5) - up to 50
• Working time with AP 500 S battery min - 60

1) Without battery, with bar and chain
2) K-factor according to DIR 2006/42/EC = 2.5 (dB (A))
3) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
4) K-factor according to DIR 2006/42/EC = 2m / s
5) Battery working times are approximate and may vary depending on application
