Function:

• Max tilling width (mm) - 450
• Max tilling depth (mm) - 260
• Forward speeds - 1
• Forward tool rotation speed (rpm) - 135 rpm

Dimensions:

• Dimension (L x W x H) (mm) - 1,155 x 510 x 1,035
• Dry weight (kg) - 24

ACC:

• Rotors/tines supplied - 4 x 4 tooth digging tines
• Wheels - Rear Transport
• Side discs - Yes
• De-thatcher / scarifier - Optional

Engine:

• Engine - 4-stroke OHC
• Engine model - GXV50
• Engine displacement (cc) - 49
• Engine net power (kW/rpm) - 1.3/4,800
• Fuel tank capacity (Litres) - 0.35
• Engine oil capacity (Litres) - 0.3
• Starter - Recoil
• Drive clutch - Automatic - centrifugal
• Transmission - Worm gear
• Sound pressure at operators ears (dB(A)) - 79.5
• Guaranteed sound power level (dB(A)) - 93
• Vibration (m/sec) - 10

Handle:

• Foldable handle - Yes
